RoadLoc® Re-usable Barrier Anchors
RoadLoc® Re-usable Barrier Anchors
The RoadLoc® is a removable, reusable epoxy anchor for asphalt and concrete. Easy to install and remove without special tools, it supports barriers, crash cushions, and poles, offering superior performance with various sizes for versatile road safety applications. The RoadLoc® is a removable, reusable epoxy anchor for asphalt and concrete. Easy to install and remove without special tools, it supports barriers, crash cushions, and poles, offering superior performance with various sizes for versatile road safety applications.
Low
Deflection
Deflection
Only 20mm deflection at 30kN
Compact
Design
Design
100mm x 200mm footprint for tight spaces
Easy
Installation
Installation
Single anchor design reduces complexity and cost
Product Information
Product Information
Product Information Product Information
- Description DescriptionRemovable and re-usable epoxy barrier anchors. Compatible with HighwayGuard, BG800, QuadGuard and moreThe RoadLoc® is a removable and reusable epoxy anchor which is designed to be removed with hand tools or battery operated impact drivers, requiring no pre-coating and no post removal special cleaning.The RoadLoc® anchor uses a custom designed insert into epoxy with a square top that allows for easy removal from epoxy.
The RoadLoc® can be installed with any epoxy.RoadLoc® Barrier Anchors can be used in both asphalt and concrete road surfaces. It has been extensively tested in both asphalt and concrete pavement conditions in tensile and shear loading. RoadLoc® consistently performs equal or better than standard anchors used for temporary road furniture.RoadLoc must be installed in accordance with the instructions and in accordance with the anchoring requirements of the product it is being used to anchor.Can be used in both asphalt and concreteCan be installed with any epoxyTested and performs equal or better than standard anchors used for temporary road furnitureEasy removal with a cordless impact driverRequires no pre-coatingAvailable in various lengths/diametersDescription DescriptionM24 Anchors – From 175mm to 450mm lengthSteel and Concrete BarriersCrash CushionsEnd TerminalsSignsStreet KerbsPoles and Bollards
Download
(301 KB)
